• Hot Rods are double forged to improve grain flow and maintain dimensional consistency
• Hot Rods are shot peened to eliminate surface stress risers and fatigue durability is improved two times over a forged rod, and over eight times when compared to a polished rod
• Double honing produces an ultra round bearing surface (50 millionths tolerance), producing a reliable high RPM connecting rod

PART 8632 INFO:

• Connecting Rod Big End I.D: 46mm
• Connecting Rod Big End Width: 23.500mm
• Connecting Rod Center-to-Center: 111.400mm
• Connecting Rod Small End I.D: 21mm
• Connecting Rod Small End Width: 19mm
• Engine Type: 4-Cycle
• Includes: Connecting Rod, Crank Pin, Crank Pin Bearing and Thrust Washers
• Pin Length: 63mm
• Washer THK: 1mm

PART 8691 INFO:

Connecting Rod Big End I.D: 38mm

Connecting Rod Big End Width: 18mm

Connecting Rod Center-to-Center: 105.500mm

Connecting Rod Small End I.D: 15mm

Connecting Rod Small End Width: 18mm

Engine Type: 4-Cycle

Includes: Connecting Rod, Crank Pin, Crank Pin Bearing and Thrust Washers

Pin Length: 53.900mm

Washer THK: 0.950mm
